Sunflower Oil Filling Machine
VKPAK designs and builds filling machines and packaging equipment for Sunflower Oil.
Sunflower oil is one of the many liquid products that VKPAK Machinery's equipment is designed to handle. We carry a wide variety of sunflower oil filling machines and other types of equipment to meet the needs of sunflower oil packaging applications, including customizable labelers, cappers, and conveyors. We'll help you choose the machinery that is right for your production line and work with you to install and maintain it.
If you would like to get started on the design and integration of a complete system of sunflower oil filling machines and other equipment, contact VKPAK Machinery for immediate assistance. We can also provide several services to help you maintain your production line's efficiency and cost-effectiveness. Our list of services includes installation, field service, operator training, performance improvement, high-speed cameras, and leasing. With VKPAK Machinery services and equipment behind your packaging operations, you can maximize the profitability and longevity of your packaging system.
Configuration List
| Descriptions | Brand | Item | Remark |
| Servo motor | Panasonic | 1.5KW | Japan |
| Reducer | Fenghua | ATF1205-15 | Taiwan |
| Conveyor motor | ZhenYu | YZ2-8024 | China |
| Servo drivers | Panasonic | LXM23DU15M3X | Japan |
| PLC | Schneider | TM218DALCODR4PHN | France |
| Touch Screen | Schneider | HMZGXU3500 | France |
| Frequency Converter | Schneider | ATV12HO75M2 | France |
| Photo electricity of inspect bottle | OPTEX | BRF-N | Japan |
| Pneumatic Element | Airtac | Taiwan | |
| Rotary Valve | F07/F05 | No Need for Oil | |
| Pneumatic actuator | F07/F05 | No Need for Oil | |
| Low-Voltage Apparatus | Schneider | France | |
| Proximity switch | ROKO | SC1204-N | Taiwan |
| Bearing | China | ||
| Lead Screw | TBI | Taiwan | |
| Butterfly valve | CHZNA | China |
Technical Parameters
| Filling Nozzles | 1-16Nozzles |
| Production Capacity | 800 -5000Bottles Per Hour |
| Filling Volume | 100-500ml,100ml to 1000ml, 1000ml to 5000ml |
| Power | 1500W to 3000W, 220VAC |
| Accuracy | ±0.1% |
| Driven | Panasonic Servo Motor |
| Inerface | Schneider Touch Screen |
Advantage of Refined Sunflower oil filling machine
- PLC control, operation on touch screen
- Panasonic servo motor driven , automatic adjust the Filling size on HMI, eg. Users want to fill 500g oil, users just input the number 500, then the machine will automatic adjust
- It is volumetric by piston, high filling accuracy
- Easy adjustment, and tools free
- The soft tubes or pipes on the filler are adapt world brand Toyox from japan
- Specially made rotary valve for oil transfer
- O seals and Rings are specially chosen for oil
Details
- Warranty: 1 Year
- Packaging Type: Bottles
- Packaging Material: Plastic, Wood
- Type: Filling Machine
- Applicable Industries: Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Advertising Company
- Condition: New
- Application: Food
- Automatic Grade: Automatic
- Driven Type: Pneumatic
- Voltage: 220V
- Place of Origin: Shanghai, China
- Brand Name: VKPAK
- Dimension(L*W*H): 2000m*1100mm*2400mm
- Weight: 800KG
- Certification: CE ISO9001
- After-sales Service Provided: Online support, Video technical support, Free spare parts, Field maintenance and repair service, Engineers available to service machinery overseas
- Key Selling Points: Automatic
- Model: VK-PF Refined Sunflower Oil Filling Machine
- Function: Sunflow oil
- Filling volume: 1000ml-5000ml 100ml-1000ml
- Filing error: 0.5%
- Name: Refined Sunflower Oil Filling Machine
- Filling material: liquid
- Key words: sunflower oil filling machine
- Material: 304ss
