Bleach Filling Machine

Controlled by Schneider servo system.
Adjustable filling speed
Accurate to ±0.1% (1000ml)
Integrated digital control with Schneider PLC and high-tech touch screen controls for easy operation.
Designed for easy changeover and cleaning.
Professional manufacturing techniques using the ISO-9001 system.
GMP standard stainless steel.
Bottom-up filling for option.
Bottle neck location.
No bottle-no fill system.
Filling zone protected by stainless steel frame
Volume is easily adjusted through touch screen. Filling pistons are controlled by servo system.
Individual piston adjustment.
Digital control system to enable multiple filling actions on the same bottle for double, triple and more.Nozzles can set to be above bottle mouth or bottom up, synchronizing with liquid level (beneath or above) to eliminate bubbling of foamy liquids.
Three-step-filling, it can fill slowly at the beginning and then accelerate to faster speed, finally slow down once again to finish up. This can prevent foamy liquids from bubbling and avoid spillage.

Rinsing System
Bleach Filling equipment applies unique overturning bottle clamp, which is hygienic and durable. This bottle clamp grips bottle at neck position, avoiding bottle mouth thread contamination caused by rubber gripper block of a traditional bottle clamp.
Filling System
Clip the bottle neck with steel starwheel. There is no need to adjust the equipment height when changing the bottle shape whose diameters have no much change.
Rotating disks all make from stainless steel. Large planar toothed bearings can ensure the stable operation of machine.
High-precision electronic liquid level filling valve makes fast and slow fillings possible.
Automatic washing cup can circularly and thoroughly clean the filling valve through CIP cleaning program.
Integrate filling valve with bottle lifting mechanism. The simplified structure makes cleaning easier and could improve the stability of the machine. Bottleneck is clipped by clippers.

1.1 The machine suits for the filling of different sizes of vessel may change the filling sizes within a few minutes.
1.2 Short filling circle, high production capacity.
1.3 Changing filling circle, high production capacity.
1.4 User may choose the filling volume and decide the filling heads per own production capacity.
1.5 The touching operation color screen, can display the production state, operation procedures and filling ways, tableau objective, operation simple and maintenance convenient.
1.6 Each filling-head is equipped with a bottle-mouth-clamping device, ensuring the injecting material correct aiming at.

Model	VK-FF automatic gravity Filling machine(corrosive liquid)
Nozzles	6	8	10	12	16	20
Idea Filling range	100-1000ml, 500-5000ml
Application bottles	Round , flat or regulars bottles
Capacity Per 1000ml	24b/m	32b/m	40b/m	48b/m	64b/m	80b/m
Power supply	220V,50hz
